We provide fiber termination boxes for indoor and outdoor use. These boxes are compatible with FTTx networks. You can mount it either on a wall or pole for fiber fusion connection, termination, splitting, and management.

Features
  • Outdoor and indoor applications
  • High quality plastic construction
  • IP55 IP Rating
  • Fiber Count: Max. 72 Fibers
  • Max. Loading PLC splitter: 2x16CH
Specifications
Mode Size A*B*C(mm) Max. Capacity Installation Size Cable-in way
FCS-2A 102*167*31 SC LC PLC D*E(mm) D(mm)
2 4 4 159*80
FCS-4A 186*116*40 4 8 4/8   195
FCS-4B 191*120*44 185*93
FCS-2B 150*120*37 2 4     60
FCS-6A 6 6
FCS-8A 213*163*47 8 16 8/16 206*129
FCS-8C 199*160*46 173*136
FCS-8E 230*180*55 8/6 81*120
FCS-12B 263*135*46.5 12 24     66
FCS-8B 250*190*39 8 16 8/16 130*82   Cut free
FCS-12D 12 24
FCS-16H 295*240*85 16 24 16 190*270
FCS-8H 225*200*65 Splitting Splicing 168*210
8 2
FCS-12C 12 12
FCS-16B 330*260*130 16 4 200*260
FCS-16C 320*240*100 190*298
FCS-16G 293*219*84 16 16 155*82   Cut free/ With cut
FCS-24A 320*240*100 24 24 190*298
FCS-24B 330*260*130 200*260
FCS-32B 420*320*130 32 8 256*400
FCS-36B 36 36 256*400
FCS-48B 48 48
Founded in 2005, KOC Communication Company has 15 years of experience in providing a full range of network hardware & components for telecommunication applications. Within our factory, we operate first-class equipment and have an expert manufacturing history of nearly 2 decades, allowing us to provide top of the line fiber optic cables, fiber connectors, fiber optic adapters, fiber optic enclosures and cabinets, and more.
